Products
Dry Bath
Welso WDDB series digital metal dry thermostat adopts advanced digital control technology, which can accurately set and adjust the temperature and time in real time to ensure uniform temperature distribution on the thermal module.
Product Details
Welso WDDB series digital metal dry thermostat adopts advanced digital control technology, which can accurately set and adjust the temperature and time in real time to ensure uniform temperature distribution on the thermal module.
This series of products is widely used in molecular biology, histology, clinical testing, environmental science and industrial laboratories.
The WDDB series provides a variety of configuration options according to different needs, and can support up to four heating modules, which can flexibly adapt to various experimental requirements.
The compact design saves the space of the operating table, takes into account high performance and convenience, and is an indispensable heating and constant temperature solution for modern laboratories.
Product features
Real-time temperature and time display
The high-definition LCD screen displays the current temperature and timing status in real time, which is convenient for users to monitor the experimental progress at any time and improve the convenience of operation.
Over-temperature protection to ensure safe operation
The built-in over-temperature protection system automatically activates the protection mechanism when the temperature exceeds the set range, effectively preventing sample damage and equipment failure, and ensuring safe use.
Compact design, saving space
The overall structure is small and easy to place in the operating table or small space of the laboratory, optimizing the laboratory layout and improving space utilization.
High-quality aluminum alloy heating module
The heating block is made of high-quality aluminum alloy, which has excellent thermal conductivity and durability, ensuring fast and uniform temperature transfer and extending service life.
Specification
Model | WDDB100 | WDDB200 | WDDB400 |
Blocks | 1 | 2 | 4 |
Temperature Range | Ambient+5°C~150°C | ||
Heating time(20℃-150℃) | ≤30m | ||
Temperature Stability at 40°C | ±0.3°C | ||
Temperature Stability at 100°C | ±0.5°C | ||
Temperature Stability at 120°C | ±1°C | ||
Temperature Display Accuracy | 0.1°C | ||
Time Setting | 0-99h59m | ||
Max Temperature | 150℃ | ||
Power | 200W | 400W | 600W |
Dimension(mm) | 260×220×100 | 260×220×100 | 360×220×100 |
Block Option
Order# | Block |
DDBB001 | 48*6mm |
DDBB002 | 48*7mm |
DDBB003 | 24*10mm |
DDBB004 | 24*12mm |
DDBB005 | 24*13mm |
DDBB006 | 12*15mm |
DDBB007 | 12*16mm |
DDBB008 | 12*19mm |
DDBB009 | 12*20mm |
DDBB010 | 8*26mm |
DDBB011 | 6*28mm |
DDBB012 | 3*40mm |
DDBB013 | 48*0.2mL |
DDBB014 | 48*0.5mL |
DDBB015 | 24*1.5mL |
DDBB016 | 24*2.0mL |
DDBB017 | 96*0.2mL |
DDBB018 | 96 well Elisa Plate |
DDBB019 | Customized Blocks Upon To Request |
