Products
Dry Bath Incubator
The WES1000 Dry Bath Incubator is a high-performance heating and cooling system utilizing advanced semiconductor technology. It features precision PID temperature control and automatic regulation, offering stable and rapid thermal response for complex experimental protocols.
Product Details
Product Description:
The WES1000 Dry Bath Incubator is a high-performance heating and cooling system utilizing advanced semiconductor technology. It features precision PID temperature control and automatic regulation, offering stable and rapid thermal response for complex experimental protocols. With flexible operation modes, interchangeable smart blocks, and safety features, the WES1000 is engineered to meet the rigorous demands of molecular biology, biochemistry, clinical diagnostics, and other laboratory applications.
Key Features:
Real-time Monitoring:
Equipped with a high-resolution LCD display that provides real-time feedback on temperature, time, lid heating status, and working mode for intuitive control and monitoring.
Integrated Block System with Built-in Sensors:
Each interchangeable block has an independent temperature sensor and semiconductor-based heating/cooling unit, ensuring uniform temperature distribution, faster ramping rates, and higher precision.
Smart Block Recognition:
Plug-and-play design allows automatic recognition of installed blocks, improving user convenience and minimizing setup errors.
Programmable Operation:
Supports multi-point (up to 5 steps) and multi-cycle (up to 99 cycles) programmable operation, enabling complex incubation protocols without manual intervention.
Adjustable Heated Lid:
Prevents condensation and maintains temperature uniformity from top to bottom. The lid temperature is independently adjustable to suit various sample types.
Safety & Reliability:
Built-in over-temperature protection, automatic restart function after power failure, and a temperature calibration feature ensure safe, uninterrupted operation.
Wide Application Range:
Ideal for DNA/RNA denaturation, enzyme reactions, sample thawing, and incubation of various microtubes and microplates.
Parameters
Model | WES1000 | |
Block | ES series | ESC series |
Temp setting range | 0℃~100℃ | -10℃~100℃ |
Temp control range | RT+5℃~100℃ | RT.-25℃~100℃ |
Time range | 1sec ~ 99h59min/∞ | 1sec ~ 99h59min/∞ |
Temp accuracy | ≤±0.3℃@37℃ | ≤±0.3℃@37℃ |
Display accuracy | 0.1℃ | 0.1℃ |
Temp uniformity | ≤±0.3℃@37℃ | ≤±0.3℃@37℃ |
Heating time | ≤12min(from 25℃ to 100℃) | ≤12min(from 25℃ to 100℃) |
Cooling time 1 | --- | ≤12min(from 100℃ to 25℃) |
Cooling time 2 | --- | ≤25min(from RT to RT-25℃) |
Heating lid temp setting range | OFF~+10℃ | OFF~+10℃ |
Heating lid temp accuracy | ≤±0.5℃ | ≤±0.5℃ |
Heating lid heating time | ≤10min(from 25℃ to 100℃) | ≤10min(from 25℃ to 100℃) |
Storage at 4℃ | --- | Yes |
Multi-points running | Yes(Max 5points) | Yes(Max 5points) |
Multi-cycle | Yes(Max 99times) | Yes(Max 99times) |
Auto running | Yes | Yes |
Auto heating | Yes | Yes |
Auto resume to run | Yes | Yes |
Capacity | See optional block | See optional block |
Power | 150W | 150W |
Voltage | AC110 or AC220V/50-60HZ | AC110 or AC220V/50-60HZ |
Fuse | 250V 3A Ф5*20 | 250V 3A Ф5*20 |
Dimension(mm) | 300*200*210 | 300*200*210 |
Weight(kg) | 4.0 | 4.7 |
